Radial Drilling Machine
Product Details:
X
Radial Drilling Machine Price And Quantity
- 1 Piece
Radial Drilling Machine Trade Information
- JNPTC, Mumbai
- 4-6 Week
- Australia South America Western Europe Middle East Africa Central America Asia Eastern Europe North America
Product Description
Radial Drilling Machine
FLOOR TABLE TYPE
- Maximum Drilling diameter : 40 to 65 mm
- Distance of spindle axis column : 320 to 1600 mm
- Spindle nose & working surface : 90 to 1220 mm
- Vertical travel of radial arm : 500 to 580 mm
- Travel of spindle head along arm : 500 to 1250 mm
- Column diameter : 300 to 350 mm
- Spindle diameter : 60 to 79 mm
- Spindle travel : 240 to 315 mm
- Spindle speed : 75 to 2000 RPM (6 to 16 step)
- Spindle feed : 0.1 to 3.2 mm/rotation (3 to 16 step)
- Size of work table : 400x350 to 500x630 mm
- Motor power : 1.5 to 3 Kw
- Weight : 1800 to 3500 Kg
